Leo Filter Press Palm Oil Franctionation Filter Press for Palm Oil Process

Leo company's product prototype.

Leo Filter Press Palm Oil FranctionationFilter Press for Palm Oil Process

Palm Oil Fractionation Filter Press for PalmOil Fats and Oils

Now we offer the following palm oil filterpress as blow:

Filter press capacity: according to palmoil flow chart capacity Filter Cake Thickness: 30mm to 40mm

Low and high pressure: 100 psi (7bar),200pis(14bar),280 psi(20bar), or high feeding pressure and

Membrane squeezing: yes, high pressuresqueezing design

Membrane Plate thickness: normally 70-80mmfor standard design

Membrane installation method: one piecetype, welded

Feeding permitted temperature: from -10 to+ 90°C

Filter plate material: Polypropylene(PP)

Membrane material: Polypropylene(PP)

Plate gasket material: anti oil food gradegaskets

Filter press closing source: Automatichydraulic closing by hydraulic system

Filter plate opening design: specially foroil industry, fast opening by multiple cylinder opening

Control systems: PLC control(AB ,LG,Siemens )

Filtrate discharge method: designed for oilcollecting only

Filter cloth washing: yes

Filter plate shifting: yes

Wetted material: Mild steel Q235A, SS304,SS316L, PP, or according to oil industry requirements

Filter press auxiliary system options:

Expansion filter capacity available forfuture capacity increasing

Explosion-proof operation design

Feeding Pump for oil industry only

Filter cloth: special designed filter clothfor palm oil fractionation filtering only

Country of Origin: China, Zhejiang,Hangzhou

Brand Name: Leo Filter Press

Testing Pressure: 1.5times as the orderedpressure
